COIL INSPECTION LINE
Coil Inspection Line ADS Unused [#6007]
1
Unused Coil Inspection Line
ADS
FOR SALE
Year when built: 2007
OFFERED SUBJECT TO BEING UNSOLD
Coil Inspection Line for sale. 1524mm x max. 2.8mm. Built: 2007. Manufacturer: ADS. For cold rolled, low carbon steel. Never used. Sold "as is, where is" off foundation.
Coil Inspection Line for sale. Never used. For cold rolled, low carbon steel coils: max. 1524mm wide x .3—2.8mm material thickness. Built: 2007. Manufacturer: ADS.
Manufacturer ADS / new 2007
Material Cold rolled, low carbon steel
Strip Width 24 - 60" / 610 - 1524mm
Strip Thickness .012 - .110" / 0.3 - 2.8mm
Coil Size
ID - 24" / 610mm
OD - 72" max / 1829mm
Wt - 60,000 lbs max / 27,272kg
Yield Strength
125,000 psi max
Shear Strength
80,000 psi max
Utilities
460 V / 3 ph / 60 Hz
80 PSIG air, 40 PSIG water
Equipment List
- Entry Coil Cars: Two
- Uncoiler
- Coil Peeler and Threading Table
- Pinch Roll
- Flattener
- Center Guide
- Strip Thickness Gauge
- Entry Crop Shear with scrap cart
- Edge Masher
- No 1 Pinch Roll
- Inspection Station & Carryover Table
- No 2 Pinch Roll
- Electrostatic Oiler
- Exit Deflector / Pinch Roll
- Recoiler with edge guide & belt wrapper
- Exit Coil Storage Saddles: Three
- Coil Scale
PHOTOS & IMAGES
(CLICK TO ENLARGE)
2
3
4
5
6
7
